Sea-Dog USB A / USB C Square Surface Mount Power Socket MPN: 426531-1

USB A / USB C Square Surface Mount Power Socket

This square surface-mount USB 3.0 & USB-C power socket charges two devices simultaneously. When split, the total 6A output is 3A per side.

Features:

• USB 3.0 features Quick Charging (QC) for supported devices gives enough power to charge phones, pads, and tablets quickly and efficiently
• USB-C features Power Delivery (PD) for faster and more flexible charging
• A protective dust cap covers ports when not in use
• Constructed of injection-molded nylon
• Easy installation requires drilling a 3/16-in. hole for the wire connection, securing it to the surface with two #6 screws (not included), and snapping the concealed fastener cover in place
• Blue LED illumination
• IP65 rating
• CE & RoHS compliant

Specifications:

• Output DC: 5V/6A
• Input: 8-32VDC
• USB-C Watts: 60W@24V
• USB 3.0 Watts: 36W@12V
• Dimensions (inch): 1-15/16” – 1-15/16”
• Depth: 3/4 in.
• Volts: 8-32
• Weight: 0.07

Specifications:

• Box Dimensions: 1"H x 3"W x 5"L WT: 0.15 lbs
• UPC: 035514433136
