Blue Sea 8184 AC Main + 6 Positions/DC Main +15 Positions MPN: 8184

$992.99
Availability: Out of stock
SKU:
CWR-14581
8184 AC Main + 6 Positions/DC Main +15 PositionsSwitches Color: WhiteFeatures:All AC and DC buses installed and fully pre-wiredLabel backlighting pre-installedON - indicating LEDs installed in all cir...

8184 AC Main + 6 Positions/DC Main +15 Positions

Switches Color: White

Features:

  • All AC and DC buses installed and fully pre-wired
  • Label backlighting pre-installed
  • ON - indicating LEDs installed in all circuit positions
  • 100 Ampere C-Series Toggle Circuit Breaker provides main circuit protection and switching for DC branch

Specifications:

  • Positions: 6 AC / 15 DC
  • Nominal Voltage: 230v AC / 12v DC
  • Height: 10"
  • Width: 14.75"
  • Depth: 3"

Included:

  • (3) 7299 A-Series White Toggle Circuit Breaker - Single Pole 8A (AC Branch)
  • (1) 7294 A-Series White Toggle Circuit Breaker - Double Pole 16A (AC Main)
  • (1) 9354 AC Voltmeter - 0 to 250v AC (AC Meter)
  • (9) 7210 A-Series White Toggle Circuit Breaker - Single Pole 15A (DC Branch)
  • (1) 7250i Circuit Breaker CA1 100A Red IP (DC Main)
  • (1) 8017 DC Analog Ammeter - 0 to 100A w/ Shunt (DC Meter)

WarningWARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Specifications:

  • Max Breaker Quantity: 6 AC / 15 DC
  • AC/DC: Both
  • Voltage: 230v/12v
  • Box Dimensions: 3"H x 7"W x 15"L WT: 8.9 lbs
  • UPC: 632085081843

Owner's Manual (pdf)
